3D CAD models
For mechanical design, renderings and animations
We offer 3D CAD models of many Noctua products via the download section of our website.
These public 3D CAD models accurately represent mounting dimensions as well as the overall external dimensions of the product. To protect our intellectual property, certain features – such as fan impeller geometries – have been slightly modified while remaining visually very close to the actual product.
Accordingly, these models are well suited for integrating our products into your own CAD designs, as well as for creating renderings, animations, and other visual outputs. However, please do not use these models for performance simulations and note that components, such as fan impellers and internal frame structures, are not fully representative of the actual product.
Disclaimer
Noctua provides CAD models on an “as is” and “as available” basis, without warranties of any kind, whether express, implied, or statutory, including but not limited to warranties of accuracy, completeness, merchantability, or fitness for a particular purpose. Noctua does not warrant that CAD models are error-free or suitable for any specific application.
The CAD models are provided solely for reference, visualisation, and integration purposes and may not be used, in whole or in part, for the manufacture, reproduction, or commercialisation of the products they represent or any substantially similar products.
Any use, modification, or reliance on these CAD models shall be at the sole risk of the user. In no event shall Noctua be liable for any direct, indirect, incidental, punitive, consequential, or special damages arising out of or in connection with the use or inability to use the provided models.
