NV-FH2
Fan hub
8 channel PWM fan hub
Up to 60W total via barrel connector or 22W via the 4-pin input
Suitable for 5V, 12V, and 24V fans
Supports both 4-pin PWM and 3-pin connectors
Easy installation
With magnetic fixture and screw-holes
Key specifications
Colour | Black |
Input connector | Barrel connector 5.5mm, 4-pin PWM |
Fan connector | 4-pin PWM |
Max. power via 4-pin PWM input | 22 W |
Max. power via barrel connector | 60 W |
Operating voltage | 5-24V |
Size | 93 x 62 x 12.5 mm (without cover) / 93 x 62 x 19 mm (with cover) |
Weight | 47 g |
Fan compatibility | All Noctua 24V, 12V, and 5V fans, many third party fans |
Warranty | 6 years |
Scope of delivery
- NV-FH2 fan hub
Extended specifications
Safety, compliance & environmental specifications
Operating temperature | -40°C to +60°C |
Flammability class | UL-94 V-0 |
Safety standards | EN 62368-1, EN 55035, EN 55032, UL-62368 |
CE | |
UKCA | |
UL |
Logistical specifications
Packaging dimensions | 28 x 145 x 109 mm |
Packaging weight (including product) | 120 g |
EAN | 9010018900156 |
UPC | 841501190155 |
Packaging unit | 60 pcs |
Packaging unit dimensions | 346 x 356 x 316 mm |
Packaging unit weight | 7.7 kg |
